Are you interested in buying an affordable laser welding machine for metal welding? Want to realize butt welding, spot welding, fillet welding, tailor welding, stitch welding and continuous welding effortlessly? Contact with Disen Laser now to understand your business and specific requirements. We’ll offer you cost-effective metal laser welding machines with professional laser welding solution to fit your custom laser welding plans, projects and ideas. The first priority of Disen Laser is finding the most satisfied laser equipment for each of customers. Disen Laser provide worldwide delivery, installation, training and service support for each of customers.
| Laser Power | 1000w/ 1500w/ 2000w |
| | |
| Fiber Length | Standard 10m |
| | |
| Price Range | $6000-$20000 |
| | |
| Laser Power | 1000w/ 1500w/ 2000w |
| | |
| Working Area | Customized |
| | |
| Price Range | $12000-$30000 |
| | |
| Laser Power | 1000w/ 1500w/ 2000w |
| | |
| Working Area | 1290/ Customized |
| | |
| Price Range | $10000-$24000 |
| | |
How does laser welding machine work?
What is laser welding machine?
Laser welding machine, the new generation of laser beam welding equipment with non-contact welding. The main components are fiber lasers, industrial chillers, welding heads, and intelligent control systems. It can also be equipped with automatic wire feeding device to achieve additive welding. The heat-affected area is small during welding, the workpiece without deformation or blackening, with large welding depth and firm welding. It can easily complete welding processes such as spot welding, butt welding, stack welding, sealing welding, seam welding, etc., with simple operation, beautiful welding seam, fast welding speed, high welding efficiency, no consumables, etc. It can perfectly replace traditional welding methods such as argon arc welding, arc welding, and gas shielded welding.
Laser welding machines can be divided into handheld laser welding machines, desktop laser welding machines, and robotic laser welding machines.
Hand-held laser welding machine: It adopts the configuration of control cabinet and fiber connection wobble welding head, which is convenient to move and flexible to use. Hand-held laser welding machine looks like the best choice for small business or non-large welding production workshops. It takes up small space and welds diversification products. This hand-held welding gun is not only convenient for small business, but also suitable for outdoor laser welding.
Desktop laser welding machine: It adopts the configuration of screw-driven three-dimensional coordinate transmission system and wobble welding head. The table can be equipped with fixtures for use, the welding accuracy is high and the speed is fast.
Robot laser welding machine: It adopts industrial six-axis linkage mechanical arm, which can move flexibly in the space area, which is convenient to adjust the movement trajectory. It has the characteristics of high stability and high precision. It can easily complete the welding requirements of special-shaped parts in the hardware, auto parts and other industries.
Laser welding machine, also called laser welder, laser beam welding machine, laser beam welder, laser welding tool, laser welder machine, laser beam welding equipment, laser welding gun, laser joining machine, laser bonding machine, laser soldiering machine.
How much is a laser welding machine?
The fiber laser welding machine price depends on your process requirement, cause the quality, service and configuration of supporting products are not the same, the power requirements are also not the same. Welcome to ask us for sample testing to ensure your solution, or you can send us the products image with specification noted.
The cost-effective laser welding machine starts as US$8000, some customers are taken aback for the price. However, the high return on investment and fast capital turnover are what the laser welding machine brings to you. The cost of a laser welding equipment can often be recovered within a year. Compared with the labor cost you pay to welding experts every year and the loss of product rejection, laser welding machine is really an economical and reliable choice.
It is worth noting that the most worthwhile advantages of laser welding machines are high input-output ratio, enhance productivity at lower operation cost and still excellent quality.
With a fiber laser welding machine, new users can learn how to weld high-quality workpieces within a few hours, without having to be busy looking for welding experts, and there is no need for a tight delivery time. With laser welding technology, you will be ahead of the market and get higher profits.
Although most metal processing manufacturers have benefited from the advantages of laser welding technology, there are still many people who are hesitant to invest in the initial stage. In order to solve this problem, please consider your processing needs and the impact of laser welding on you. Consult industry expert laser welding machine manufacturer Disen Laser, we can help evaluate your machined parts, answer questions and show you how laser welding can help you make money.
Laser Welder Application
Industrial laser welder apply to weld stainless steel, carbon steel, copper, silicon steel sheet, aluminum, gold, tantalum, silver, nickel, chromium, titanium, and other metals or their alloys as well as various dissimilar materials.
Widely used in complex irregularities in sheet metal processing, cabinets and kitchens, furniture and home appliances, billboards, advertising characters, molds, handicrafts, hardware tools, stair lifts, shelves, ovens, water tanks, metal door window and guardrails, stainless steel furniture, distribution boxes and other industries welding process.
Some of the most popular applications and industries that laser welding is used for, are listed below:
· Automobile Manufacturing Industry
The automotive industry is one of the main application areas of laser beam welder. When a car is running, each component and structure will be impacted by different degrees of force, which requires the overall structural density of the car to support. In the automobile manufacturing industry, fiber laser welding is usually used for the welding of key parts of the car body and parts with special requirements for the welding process. For example, it can be used for welding inner and outer panels to solve problems of welding strength, efficiency, appearance, and sealing; the trunk cover welding has advantage for right angle lap joints; tailored welding of car door integrated can improve welding quality and efficiency effectively. Laser welding has the advantages of high energy density, narrow heat-affected area, fast welding speed, easy automatic control, and no need for subsequent processing. The flexibility and controllability of fiber laser welder meets the processing of various automobile materials, reduces production costs, improves production efficiency. At the same time, it is applied to the welding of automobile parts, such as cylinder head gaskets, fuel injectors, spark plugs, etc., which brings huge benefits to the automobile manufacturing industry.
· Shipbuilding Industry
Laser welding technology is also applicable to shipbuilding. The parts on ships require more precise welding effects. For example, precision parts such as rudders, driving screws and control devices can be welded to the required tolerances by precision laser welding, so that the ship can be realized higher sailing speed and consume less fuel.
· Cabinet Kitchenware Industry
In order to make stainless steel cupboard and kitchenware more beautiful, the laser beam welding tool adopts high-power continuous seamless welding, no secondary treatment, no consumables, simple and convenient operation, low-carbon and environmentally friendly process. Fiber laser welding technology is non-contact processing, there is not affected by mechanical stress or mechanical extrusion. Compared with traditional arc welding, laser welding can save about 80%-90% of electric energy, reduce processing costs by about 30%, and greatly improve welding accuracy. It can weld special-shaped steel and special-shaped metal, and easily complete mechanization and automation. Fast speed, small deformation, small heat-affected area, high aspect ratio. The welding seam is smooth, beautiful, without air holes, and treatment is not required after welding. More and more furniture and home appliance companies have purchased laser welding machines and use it to gain more benefits.
· Door, Window and Guardrail Industry
In the field of home improvement, more and more stainless steel materials are used, including some stainless steel doors, windows and guardrails, and precision welding equipment is also required for welding during the processing process. The fiber laser welder machine can reduce the preparation work of the workpiece before welding greatly, and reduce the technical ability for the welding operator. We only need to adjust the welding parameters according to the thickness of the stainless steel material to get a perfect welding result. Laser welding stainless steel has high precision, clean and beautiful welding seams, and better welding strength.
· Aerospace Industry
Compared with electron beam, plasma beam and other traditional welding methods, laser welding has unique advantages, such as small heat influence, good sealing, and processing in special environments such as vacuum. Therefore, laser welding technology is widely used Aerospace industry. In the aircraft fuselage manufacturing process, laser welding is used instead of riveting, which can reduce the weight of the fuselage by 20%, which greatly promotes the development of the aerospace industry. At the same time, the laser fiber welding technology solves the problem of difficult welding of thin-plate alloy materials, and the deformation of the components is small, the joint quality is good, and the reproducibility is good.
· Electronics Industry
In the electronics industry, usually relatively small electronic components need to be welded. Therefore, industrial laser welding technology gives full play to the advantages of low thermal influence in the electronics industry. In the sensor and thermostat industries, traditional welding processes were mainly used for hermetic welding in the past, such as plasma welding, argon arc welding, high-frequency welding and other contact welding method, which had the problems of large deformation and large thermal influence, and had high penetration, It is easy to damage the internal components, and there are also disadvantages such as unstable welding quality, consumables polluting the environment, and excessive dust in the welding process. Advanced laser welding technology can effectively overcome the problems of large deformation and high temperature rise caused by the traditional welding process.
· Tool Manufacturing Industry
Fiber laser welder is widely used in manufacturing tools due to its high welding accuracy and has become a substitute for etching process. It is a solution to the difficulties faced by modern industry to realize the precision casting, stamping, die-casting and forging of the base material through intelligent laser welding and composite manufacturing of laser increase and decrease materials.
· Precision Parts Welding
Chinese laser welding machine has the characteristics of high precision and small heat affected area, and the base material is basically not deformed, so it is suitable for welding precision metal parts.
· Medical Devices Welding
Laser welding tool is non-contact welding type, and there is no waste splash during the process, so it can ensure that the medical equipment that needs to be hygienic is always kept clean.
Benefits & Advantages of Laser Welder
· Fast Speed, Small Deformation
Laser welding technology realizes welding automation. The high-density energy laser beam can complete the melting or vaporization of the base material quickly, without affecting the surrounding materials, reducing the distortion and deformation of the parts, especially effective the demand for large welding volume and high material deformation requirements, such as automobile manufacturing industry and jewelry industry.
· High Accurate
Laser welding is high precision and controllability. The laser allows fractional, very fine, very clean, even almost invisible welding, and can also split the laser beam into several beams to provide more precise welding. Laser welding particularly suitable for welding small parts, such as the electronic component industry and aerospace manufacturing.
· Wide Application Range
Laser welding machine is mainly used for welding metals, including refractory metals, such as stainless steel, carbon steel, iron, copper, aluminum and other common metal materials and their alloys. It can also be adapted to welding parts of various shapes and materials, including special-shaped welding, fillet welding, intermittent welding, spot welding, butt welding, lap welding, slot welding, backing welding, groove welding and most welding types.
· Low Maintenance Cost
The laser welding adopts non-contact operation, so the machine has no wearing risk. And there is no need to replace tools or electrodes, the operation cost is lower. The wearing parts of laser welding machine are only protective lens and welding copper nozzle with cheap cost. Additional, welding experts is not necessary, the common operator can use the machine after 30 minutes training, and the welding results don’t need to be polished again, saving labor costs.
· High Welding Quality
The high automation allowed in the laser welding process makes it possible to detect and solve most welding quality problems, and the welding results are highly repeatable and consistent. Equipped with water-cooled equipment, it can work continuously for 24 hours.
· Environmental Friendly
Traditional arc welding will produce a large amount of dust and scum during welding process, which is harmful to the environment. Laser welding doesn’t produce waste and meets the requirements of green production and sustainable development.
Compared with traditional arc welding, electric fusion welding(EFW), fusion gas welding(FGW), electric resistance welding(ERW), gas-shielded welding, plasma welding, TIG welding, MIG welding, the precise control of laser beam welding provides lots of advantages:
Weld strength: laser welding has narrow weld seams, good depth-to-width ratio and higher strength.
Heat-affected area: The heat-affected area is small, cools quickly, and the surrounding materials are not affected.
Wide range of applications: used for welding carbon steel, high-strength steel, stainless steel, copper, aluminum and other common metals, precious metals and dissimilar materials.
Precision work: the high-power controllable laser beam allows precision welding of micro-components.
No damage to the base material: In all welding methods, laser welding keeps the parts with minimal deformation or shrinkage.
No contact welding: There is no direct contact between the laser head and the base material.
Environmental friendly: Laser welding does not require auxiliary materials, so the amount of waste generated is very small.
But it should be noted that the laser welding machine also has certain disadvantages:
1. Metal laser welding machine is expensive and the initial investment is high.
2. High assembly accuracy is required during the processing. When using fixtures, you must ensure that the final position of the weldment is aligned with the welding point that the laser beam will act on to avoid deflection of the laser beam on the part.
3. The welding energy conversion efficiency is low, usually less than 10%.
4. The weld is fast solidified, taking into account the influence of porosity and brittleness.
5. The maximum welding thickness is 20mm, and laser welding is not suitable for the production line.
What parameters should be checked?
Disen Laser recommends that you verify several parameters before each use of the laser welding machine to ensure that the laser welding machine can perform at the highest level of production.
1. Energy parameters
Disen Laser reminds you that before each use, you need to adjust the energy parameters and adjust the power ratio to the value required by the welding process to prevent energy waste and substrate waste.
2. Beam diameter
Disen Laser reminds you that a laser beam with a diameter between 0.2-2mm is conducive to better welding results, and the beam diameter directly affects the welding performance.
3. Pulse frequency
Disen Laser reminds you that the pulse frequency is inversely proportional to the pulse energy. The pulse frequency should be determined according to the thickness of the base material. Too high a pulse frequency will result in a low pulse energy, thereby reducing welding efficiency.
4. Laser pulse waveform
Disen Laser reminds you to change the waveform according to the metal material to be welded. If an inappropriate waveform is used, 60% to 98% of the laser energy will be lost, which will directly lead to the failure of the welding operation.
For specific parameter configuration, please contact Disen Laser professional sales engineer for guidance.
When choosing a laser welding machine, you must understand these 18 common problems:
1. What materials can the laser welding machine be applied to?
Stainless steel, carbon steel, aluminum, copper, galvanized sheet and other metal materials and their alloys.
2. Can the laser welder machine weld hot-dip galvanized sheet?
cold galvanized sheet and hot-dip galvanized sheet can be welded perfectly by laser welder machine.
3. How about the welding strength of the laser welding machine?
Enough hot melt material is important while operating laser welding machine, its welding strength is higher than traditional arc welding and gas-shielded welding.
4. If there is a gap between the materials, can a laser welding machine be available?
It is recommended that the welding seam be controlled within 1.5mm, which can be used with automatic wire filling equipment.
5. Can the laser beam welding tool weld different metal materials together?
Yep of course, dissimilar metal materials welding is available.
6. What's the material thickness suitable for laser welding equipment?
The single-side welding penetration depth can reach 4mm, which is suitable for welding 0.5-5mm metal materials.
7. What is the area of the handheld laser welding machine?
The volume of the handheld laser welding machine is approximately: 1200mmX800mmX1300mm.
8. What is the power of the laser welding machine?
There are three powers: 1000W, 1500W, and 2000W. The thickness of the material that can be welded is proportional to the laser power.
9. Does the laser welding machine need shielding gas?
Requires nitrogen or argon.
10. Will the laser welding tools consume a large amount of shielding gas?
The laser welding machine can save 1/2 of the gas compared with the traditional welding machine.
11. What are the advantages of laser welding machine?
Small heat-affected area, small material deformation, fast welding speed, no grinding, no welding experts.
12. Does the laser welding machine need to focus?
Just once during installation, then you can enjoy the welding processing.
13. What wearing parts does the laser welding machine have?
Protecting the lens and welding copper nozzle, it’s very cheap.
14. Can the laser welding machine be repaired?
It is available but not recommended.
15. Is the laser welding effect good?
In laser welding, you will get a more precise weld, and the finish is excellent. The weld is also very strong. Therefore, this manufacturing process is very suitable for fine parts. You can also use it without any area limited.
16. Can aluminum be laser welded?
Laser welding is commonly used to join aluminum and its amalgam.
17. Can fillers be used in laser welding?
You can use filler materials for laser welding, wire or powder. Nevertheless, most industrial laser welding applications use welding wire.
18. How to operate the laser welding machine?
Please contact Disen Laser's professional engineer team.
How to buy a laser welding machine?
1. Consult: We will certainly recommend the most appropriate laser welding equipment to you after being notified by your demands.
2. Quotation: We will offer you with our detail quote according to the consulted from laser welding equipment. You will certainly obtain the most appropriate specs, the best accessories and also the affordable price.
3. Details Consultation: Both sides very carefully review as well as go over all the information (technological parameters, specs and also business terms) of the order to omit any type of misconception.
4. Placing Order: If there is no doubt, we will send you the PI (Proforma Invoice), and after that we will authorize contract with you.
5. Manufacturing: We will arrange the machine production as soon as obtaining your signed sales contract and deposit. The current information concerning manufacturing will certainly be upgraded and informed to the purchaser during the manufacturing.
6. Quality Control: The whole production treatment will be under normal assessment as well as strict quality control. The total machine will be evaluated to ensure they can work extremely well prior to out of factory.
7. Shipment: Delivery will certainly begin as the terms in the contract after the laser welder purchaser's verification.
8. Custom Clearance: The necessary shipping documents will be supplied and delivered to the buyer as well as ensure a smooth customs clearance.
9. Support and Service: We will offer specialist technical assistance as well as cost-free solution by Email, Phone, WhatsApp, Skype, Wechat, Online Live Conversation, Remote Service. We additionally have door-to-door service in most areas.
Final Thoughts about Laser Welding Machine
We really hope that you have enjoyed the specific knowledge that we want to share with our visitors. This info will assist you in determining the best laser welding machine in 2022, that will fit your business the most.
Summing up, you can select from the option of integration, the power of the fiber laser welding machine, the size, mobility, and the price that you wish to pay for the machine.
Just click the link and our professional sales manager will be at your disposal. Disen Laser is the professional supplier of laser application solution, we can lead you in the light of our experience to get the best laser welding machine. So what are you waiting for, just click and contact us now!
